19" two‑section acoustic wall cabinet with 2 fans, RAL9005 black, 20U

Technical Details:

• Lining with high‑quality flame‑retardant acoustic foam
• Active ventilation: via 2 fans in the roof
• Protection rating IP20
• Lockable safety‑glass door with steel frame
• 210° door opening angle
• Single‑point locking on the front door
• Side panels are lockable and removable
• 483 mm (19") mounting rails installed at the front and rear inside the cabinet, galvanized
• 483 mm (19") mounting rails are depth‑adjustable and marked with height units
• Maximum installation depth: 450 mm
• Cable entry at the rear and bottom with plastic cover, and at the top with sliding cover
• Roof prepared for installation of a fan module (pre‑punched cutouts)
• Ventilation slots for active and passive air intake and exhaust
• Multiple grounding points inside the cabinet for installed components
• Includes installation kit (screws, cage nuts, washers)
• Delivered fully assembled
• Installation depth for components min.–max.: 320–450 mm
• IP protection class: IP20
• Color: black, RAL9005
• Depth: 600 mm
• Front door: single‑leaf glass door, reversible mounting
• Rack units: 20U
• Load capacity: 100 kg
• Assembled: yes
• Cabinet type: wall‑mount enclosure
• Width: 600 mm
